J Customized high quality fancy central beam staircase

  • Stringer/beam: Carbon steel/stainless steel
  • MOQ:1 set
  • Treads: solid wood/glass/granite
  • Color:customized
  • Description:Prima housing manufacturer offer you one-stop housing service, various designs for choosing, support custom design
  • Inquiry
Staircase Size:
1. Floor to floor height:
customized as your job site
2. Width:
850 - 1800mm/Customized
*Dimensions will vary according to measurements of stairs.


Material:
1. Beam:
stainless steel / carbon steel
2. Tread:
laminated glass / solid wood
3. Handrail:
stainless steel / carbon steel / solid wood / PVC
4. Baluster:
stainless steel / carbon steel / aluminum
5. Rod:
stainless steel / carbon steel / aluminum






Component & Size (mm)
1. Beam:
100*200*6mm center beam/300*10/12mm side beam
300*(5+5)mm u channel beam/ 108*4mm center post
2. Tread thickness:
10+1.52+10mm or 12+1.52+12mm for glass tread;customized
30 - 92mm for solid wood tread
3. Handrail:
dia=50.8mm or square=50*50mm
4. Baluster:
dia=50.8mm / 38mm or square=50*50mm
5. Rod/Wire:
dia=4/6/8mm
6. Glass:
10mm/12mm/15mm tempered glass or 6+1.52+6mm/8+1.52+8mm laminated glass



Finish:
1. Stainless steel:
mirror / satin
2. Carbon steel:
hot dip galvanizing / powder coating / painting
3. Aluminum:
powder coating / galvanized / oxidize
4. Solid wood:
painting
5. Glass:
round edge & polished edge
Note
We still have more designs of the staircase
Detail Images

Material Description:
Tread: Glass
Thickness: 10 mm+1.52+10 mm/12 mm+1.52+12 mm

Material: Laminated Glass & Tempering Glass & Frosted glass
Material Description:

Tread: Wooden
Thickness: 30mm / 40mm/50mm / 60mm / 82mm/92mm

Material: Rubber wood / Beech wood / Oak wood / White oak / Red oak / teak wood / Sapele wood
The Optional color can be customized:
Rose wood/Sapele wood/Teak/Burly wood/Bubinga-A/Bubinga-B/Rich red/ Black-Walnut-A/Black-Walnut-B/Black/White/Customized
Handrail/Glass or rod bar wall fence
Handrail: Wooden
Size: φ40mm / φ50mm / φ60mm / φ80mm /□50*50mm

Material: Rubber wood / Beech wood / Oak wood / White oak / Red oak / teak wood / Sapele wood

Handrail: Stainless Steel
Size: φ32mm / φ38mm / φ40mm / φ50.8mm φ60mm / □38*38mm / □50*50mm / □60*30mm

Material: SUS201 / SUS304 /SUS316


Company Profile

1 , Who We Are?
Professional Staircase, Balustrade Manufacturer.

2 , What Can We Do?
Providing high quality products in a wide variety of styles and sides for all custom staircase, railing and shower enclosures at competitive price. Also we can provide the professional solution for your reference based on your project request.

3 , Who Do We Work With?
We mainly worked with the developer, contractor, home owner, designer and the architect. Worked for New Building Residential,
Commercial and individual Houses or house renovate.

4 , Which Countries Do We Worked In?

Till now we have done projects in Australia, America, Canada, UK, Sweden, Norway, Maldives, Mauritius, British Virgin, Haiti, Thailand, Ghana, Kenya etc.



Packing & Delivery


Packing Details : plywood for better protection of goods and easier for loading and unloading
Handrail: woven bag
Balutser: carton package
Glass: plywood package or solid wood package
Shipping: 30-45 days after the shopping confirmed
